DS-2SE4C225MWG-E/26F0
1087.11 azn
Stokda yoxdur
Haqqında
DS-2SE4C225MWG-E/26 F0 2mp IR 100m LED 30m TandemVu 6+2MP 25X Colorful & IR Panoramic & PTZ Camera H
| Növ | IP |
| Meqapixel | 2 MP |
| Obyektiv | PTZ |
| İşıqlandırma | LED |
| İşıqlandırma məsafəsi | 30 m |
| Qoruma | IP66 |
| Material | Plastik |
Ətraflı
| Camera | |
| Image Sensor | [Bullet channel]: 1/2.5" Progressive Scan CMOS; [PTZchannel]: 1/2.8" progressive scan CMOS |
| Max. Resolution | [Bullet channel] 3632 × 1632, [PTZ channel] 1920 × 1080 |
Min. Illumination | [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light; [PTZ channel]: Color: 0.005 Lux @ (F1.6,AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | 1 s to 1/30,000 s |
| Slow Shutter | yes |
| Zoom | [PTZ channel] 25 × optical, 16 × digital |
| Day ＆ Night | ICR |
| White Balance | auto,ATW,sodium lamp,fluorescent lamp,indoor,outdoor,MWB,Locked WB |
| Lens | |
| Focal Length | [Bullet channel]: 2.8 mm; [PTZchannel]: 4.8 to 120 mm, 25× optical |
| Zoom Speed | [PTZ channel]: approx. 3.6 s |
FOV | [Bullet channel]: Horizontal field of view: 180±10°, Vertical field of view: 80±5°; [PTZ channel]: Horizontal field of view: 54.8° to 2.8° (wide-tele), Vertical field of view:31.4° to 1.5° (wide-tele), Diagonal fieldof view: 62.2°to 3.2° (wide-tele) |
| Focus | semi-auto,manual,auto |
| Aperture | [Bullet channel]: F1.0; [PTZ channel]: F1.6 |
| Illuminator | |
| Supplement Light Type | [PTZ channel]: IR; [Bullet channel]: White Light |
| Smart Supplement Light | Yes |
| Supplement LightRange | [PTZ channel]: up to 100 m; [Bulletchannel]: up to 30 m |
| PTZ | |
| Movement Range (Pan) | 360° |
| Movement Range(Tilt) | -15° to 90° (auto flip) |
| Pan Speed | pan speed: configurable from0.1° to 80°/s;preset speed: 80°/s |
| Tilt Speed | tilt speed:configurable from 0.1° to 80°/s, presetspeed 80°/s |
| Proportional Zoom | yes |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans |
| Power-off Memory | yes |
| Park Action | preset,pattern scan,patrol scan,auto scan, tilt scan,random scan,frame scan,panorama scan |
| 3D Positioning | yes |
| PTZ Status Display | yes |
| Preset Freezing | yes |
| Scheduled Task | preset,pattern scan,patrol scan,auto scan, tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output |
| User/Host | 32 |
| Security Measures | Authenticated username and password, MAC address binding,HTTPS encryption,802.1X authenticated access,IP address filter |
| Client | iVMS-4200,Hik-Connect |
| Image | |
| Image Settings | sharpness, saturation, brightness, contrast |
| Day/Night Switch | day, night,auto, scheduled-switch |
| Wide Dynamic Range (WDR) | [Bullet channel] Digital WDR [PTZ channel] 120 dB WDR |
| SNR | ≥ 52 dB |
| Defog | Digital defog |
| Image Stabilization | EIS |
| Image Enhancement | BLC,HLC,3D DNR |
| Regional Focus | Yes |
| Regional Exposure | Yes |
| Image Parameters Switch | Yes |
| Privacy Mask | [Bullet channel] 8 programmable polygon privacy masks, [PTZ channel]24 programmable polygon privacy masks; mask coloror mosaic configurable |
| Interface | |
| Communication Interface | RJ45, self-adaptive 10M/100M Ethernet port |
| On-board Storage | Built-in memorycard slot, supportMicro SD /Micro SDHC/Micro SDXC, up to 256GB |
| Alarm Input | 1 alarm input |
| Alarm Output | 1 alarm output |
| Audio Input | 1 audio input,2.0 to 2.4Vp-p, 1k Ohm±10% |
| Audio Output | 1 audio output, line level, impedance: 600 Ω |
| Reset | yes |
| Event | |
| Basic Event | Motion detection,video tampering alarm, exception,alarm inputand output |
| Smart Event | audio exception detection,region entrance detection,region exiting detection,intrusion detection,Line crossing detection |
Linkage | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,audible warning,and PTZ actions(such as preset, patrolscan, pattern scan) |
| Smart Linkage | panorama linkage |
| Deep Learning Function | |
Face Capture | Detects up to 5 faces simultaneously, Supports detecting, tracking, capturing, grading, selecting of face in motion, andoutputs the bestface picture |
| General | |
| General Function | mirror,password protection,watermark |
| Power | 12VDC, PoE+ |
Power Consumption and Current | Max. 24 W, including max. 2.6 W for heaterand max. 11 W for supplement light |
| Operating Conditions | -30℃ to 65℃ (-22°F to 149°F) ,humidity lower than 90%RH |
| Demist | Demist by heating the glass |
| Material | ADC12 |
| Dimensions | Ø 166 mm × 302.6 mm (Ø 6.5" × 11.9") |
| Weight | Approx. 2.4 kg (13.2lb.) |
| Approval | |
| Protection | IP66 Standard, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Exception Detection | IP address conflict, HDD full, illegal login, HDD error,network disconnected, Abnormal Restart |
| Video | |
| Region of Interest (ROI) | 8 fixed regions for each stream |
Main Stream | [Bullet channel] 50 Hz: 25 fps(3632 × 1632, 3680 × 1656) 60 Hz: 30 fps(3632 × 1632, 3680 × 1656) [PTZ channel] 50 Hz: 25 fps(1920 × 1080, 1280 × 960,1280 × 720) 60 Hz: 30 fps(1920 × 1080, 1280 × 960, 1280 ×720) |
Sub-Stream | [Bullet channel] 50 Hz: 25 fps(1200 × 536, 960 ×432) 60 Hz: 30 fps(1200 × 536, 960 ×432) [PTZ channel] 50 Hz: 25 fps(704 × 576, 640× 480, 352× 288) 60 Hz: 30 fps(704 × 480, 640× 480, 352× 240) |
Third Stream | [Bullet channel] No [PTZ channel] 50 Hz: 25 fps(1920 × 1080, 1280 ×960, 1280 × 720,704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps(1920 × 1080, 1280 ×960, 1280 × 720,704 × 480, 640 × 480, 352 × 240) |
| Video Compression | H.265,H.264,MJPEG |
| Video Bit Rate | 32 kbps to 16384kbps |
| H.264 Type | baseline profile,main profile,high profile |
| H.265 Type | main profile |
| H.264+ | yes |
| H.265+ | yes |
| SVC | yes |
| Audio | |
| Audio Compression | G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3 |
Audio Bit Rate | MP2L2: 32 Kbps, 40 Kbps, 48 Kbps, 56 Kbps, 64 Kbps, 80 Kbps, 96 Kbps, 112Kbps, 128 Kbps, 144 Kbps, 160 Kbps, 192 Kbps, AAC-LC: 16 Kbps, 32 Kbps, 64 Kbps , MP3: 8Kbps, 16Kbps, 24Kbps, 32Kbps, 40Kbps, 48Kbps, 56Kbps, 64Kbps, 80Kbps, 96Kbps, 112Kbps, 128Kbps, 160Kbps, 192Kbps, 224Kbps, 256Kbps, 320Kbps |
| Audio Sampling Rate | MP2L2: 16 kHz, 32 kHz, 48 kHz; AAC-LC: 16 kHz, 32 kHz, 48 kHz; PCM: 8 kHz,16 kHz, 32 kHz, 48 kHz; MP3:8 kHz, 16 kHz,32 kHz, 48 kHz |
| Environment NoiseFiltering | yes |
| Smart Features | |
| Smart Record | ANR,Dual-VCA |
| Network | |
| API | ISAPI,SDK,ISUP,ONVIF |
| Web Browser | IE11+, Chrome57+, Firefox52+, Safari12+, Edge79.0.309.65+ |
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Protocols | IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP, UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,R TP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour, WebSocket,WebSockets,SRTP |
| Simultaneous Live View | 20 |
