DS-2CD2T83G0-I8
476.05 azn
Hikvision
IP
8 MP
80 m
Sabit
4
İR
IP67
Metal
Haqqında
| Növ | IP |
| Meqapixel | 8 MP |
| İşıqlandırma məsafəsi | 80 m |
| Obyektiv | Sabit |
| Fokus | 4 |
| İşıqlandırma | İR |
| Qoruma | IP67 |
| Material | Metal |
Ətraflı
Camera
| Matrix | 1/2.5'' Progressive Scan CMOS |
| Electronic shutter speed | Color: 0.01lux@(F1.2,AGC on), B/W: 0.028lux@(F2.0,AGC on), 0lux with IR |
| Electronic shutter | 1/3s ~ 1/100,000s, support slow shutter |
| Lens | 2.8mm, 8mm @F2.0 |
| Viewing angle | 2.8mm: horizontal: 102°, vertical: 53°, diagonal: 124° 8mm: horizontal: 40°, vertical: 25°, diagonal: 53° |
| Focusing | Fixed |
| Day/night mode | Mechanical IR filter |
| Adjusting the installation angle | Rotation: 0° - 360°; Tilt: 0° - 100°; Rotation: 0° - 360° |
Compression
| Video compression | Main Stream: H.265/H.264 Sub Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264 |
| H.264 profile | Main Profile/High Profile |
| H.265 profile | Main Profile |
| Video bitrate | 256 kb/s – 16 Mb/s |
| Maximum resolution | 3840×2160 |
| Main thread | 50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 15 fps (3840 × 2160), 20fps (307 2 × 1728), 30fps ( 2560×1440, 1920×1080, 1280×720) |
| Additional stream | 50Hz: 25fps (640×480, 640×360, 320×240) 60Hz: 30fps (640×480, 640×360, 320×240) |
| Third stream | 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Framing the target | No |
| Image Settings | Saturation, brightness, contrast, sharpness, mirroring and privacy mask are adjustable via client software or web browser |
| Image enhancement | 120dB WDR, 3D DNR, BLC, ROI |
| Day/night switching | Auto/schedule/alarm |
| Note: | When the main stream resolution is 2944 × 1656 and higher, the maximum frame rate for all streams is 20fps |
Smart video analytics
| Behavior Analysis | Line crossing, intrusion detection |
| Face detection | Eat |
| Surveillance area | Support 1 fixed zone for main and sub stream |
Net
| Network storage | NAS (NFS,SMB/CIFS support), ANR |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Safety | User authentication, watermarking, IP address filtering, anonymous access |
| Compatibility | ONVIF(PROFILE S,PROFILE G), ISAPI |
| Alarm Triggered | Smart Features, Network Disconnection, IP Address Conflict, Storage Errors |
| Alarm Actions | Notifying the client, sending email, uploading to FTP, activating the recording channel |
| Client | iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 |
| Web browser | IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
Interfaces
| Network interface | 1 RJ45 10M/100M self-configuring Ethernet port |
| Video output | No |
| S.V.C. | Support H.264 and H.265 decoding |
| Local storage | Slot for microSD/SDHC/SDXC up to 128GB |
| Reset button | Eat |
Basics
| Nutrition | DC12V±25%/coaxial power supply Φ 5.5mm PoE(802.3af, class 3) |
| Power consumption | 12V, 0.7A, max. 7.5W PoE (802.3af, 36V to 57V), 0.3A to 0.2A max. 9W |
| Working conditions | -40 °C…+60 °C, humidity 95% or less (non-condensing) |
| Protection | IP67 |
| IR illumination range | Up to 80m |
| Housing material | Metal |
| Dimensions | Camera: Φ 104.8 × 299. mm Box: 386 × 156 × 155 mm |
| Gross weight | 1.2kg |
