DS-2CD1043G0-IUF
149.02 azn
Stokda yoxdur
Haqqında
DS-2CD1043G0-IUF 2,8mm 4mp IR30m Mic Bullet IP KAMERA HIKVISION
| Növ | IP |
| Meqapixel | 4 MP |
| Mikrofon | Mic |
| Obyektiv | Sabit |
| Fokus | 2.8mm |
| İşıqlandırma | İR |
| İşıqlandırma məsafəsi | 30 m |
| Qoruma | IP67 |
| Material | Metal |
| Yaddaş | MicroSD |
| İş mühiti | Outdoor |
Ətraflı
| Camera | |
| Image Sensor | 1/3" progressive scan CMOS |
| Max. Resolution | 2560 × 1440 |
| Min. Illumination | Color: 0.01Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day &Night | IR cutfilter |
| Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 180°, rotate:0° to 360° |
| Lens | |
| Lens Type | Fixed focallength, 2.8 and 4 mm optional |
| Focal Length& FOV | 2.8 mm,horizontal FOV 98.0°,vertical FOV 53.1°,diagonal FOV 114.7° 4 mm, horizontal FOV 78.7°, vertical FOV 43.1°, diagonal FOV 92.3° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F2.0 |
| Illuminator | |
| Supplement LightType | IR |
| Supplement LightRange | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video | |
Main Stream | 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 30 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps(640 × 480,640 × 360) 60 Hz: 30 fps(640 × 480,640 × 360) |
| Video Compression | Main stream:H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG |
| Video BitRate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Region of Interest (ROI) | 1 fixedregion for mainstream |
| Audio | |
| Audio Compression | -UF: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio BitRate | -UF: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps(G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
| Audio Sampling Rate | -UF: 8 kHz/16kHz |
| Environment Noise Filtering | -UF: Yes |
| Network | |
| Protocols | TCP/IP, ICMP,HTTP, HTTPS, FTP,DHCP, DNS, DDNS,RTP, RTSP, RTCP,NTP, UPnP, SMTP, IGMP,QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous LiveView | Up to 6 channels |
| API | Open Network Video Interface, ISAPI |
| User/Host | Up to 32 users.3 levels: administrator, operator and user |
| Client | iVMS-4200, Hik-Connect |
Web Browser | Plug-in required live view: IE 10+ Plug-in freelive view: Chrome57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Image | |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC,white balance adjustable by client software or web browser |
| Day/Night Switch | Auto, Schedule, Day, Night |
| Wide Dynamic Range (WDR) | 120 dB |
| Image Enhancement | BLC, 3D DNR |
| Interface | |
| Ethernet Interface | 1 RJ4510 M/100 M self-adaptive Ethernet port |
| On-Board Storage | -UF: Built-in memory card slot,support microSD card,up to 256 GB |
| Built-in Microphone | -UF: Yes |
| Reset Key | -UF: Yes |
| Event | |
| Basic Event | Motion detection, video tampering, exception |
| Linkage | Upload to FTP, notifysurveillance center, sendemail -UF also supports: uploadto memory card,trigger recording, triggercapture |
| General | |
| Power | 12 VDC± 25%, 0.4 A, max.5 W, Ø5.5 mm coaxialpower plug PoE: IEEE802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
| Material | Metal &Plastic |
| Dimension | 177.6 mm × 66.2mm × 67.8 mm (7.0" × 2.6" × 2.7") |
| Package Dimension | 216 mm × 121mm × 118 mm (8.5" × 4.8" × 4.6") |
| Weight | Approx. 270g (0.6 lb.) |
| With PackageWeight | Approx. 490g (1.1 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Startup andOperating Conditions | -30 °C to 60 °C (-22°F to 140 °F). Humidity 95% or less(non-condensing) |
| General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Approval | |
EMC | FCC SDoC(47 CFR Part15, Subpart B); CE-EMC (EN 55032: 2015,EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011+A1: 2014); RCM(AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009+ Am 2:2013, IEC 62368-1:2014); CE-LVD (EN60950-1:2005 + Am 1:2009 + Am 2:2013,IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach(Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC60529-2013) |
