DS-2CD1021G0E-I-ECO
49.02 azn
Haqqında
DS-2CD1021G0E-I/ECO 2.8mm 2MP NETWORK KAMERA HIKVISION
| Növ | IP |
| Meqapixel | 2 MP |
| İşıqlandırma məsafəsi | 30 m |
| Obyektiv | Sabit |
| Fokus | 2.8 |
| İşıqlandırma | İR |
| Qoruma | IP67 |
| Material | Plastik |
Ətraflı
| Camera | |
| Image Sensor | 1/2.8" progressive scan CMOS |
| Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100, 000 s, support slow shutter |
| Lens | 2.8 mm @F2.0, horizontal field of view105.8°, 4 mm @F2.2, horizontal field of view 83.6° 6 mm @F2.0, horizontal field of view 55° |
| Lens Mount | M12 |
| Day &Night | IR cut filterwith auto switch |
| 3-Axis Adjustment (Bracket) | Pan: 0° to 360°, tilt:-90° to 90°, rotation: 0° to 360° |
| DNR (Digital Noise Reduction) | 3D DNR |
| WDR (Wide Dynamic Range) | Digital WDR |
| Compression Standard | |
| Video Compression | Main stream: H.264+/H.264 Sub stream: H.264/MJPEG |
| H.264 Type | Baseline profile/Main profile |
| Video Bit Rate | 32 Kbpsto 8 Mbps |
| Image | |
| Max. Resolution | 1920 × 1080 |
| Main Stream Max. Frame Rate | 50Hz: 25fps @(1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps@(1920 × 1080, 1280 × 960, 1280 × 720) |
Sub-stream Max. Frame Rate | 50Hz: 25fps @(704 ×576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps@(704 × 480, 640 ×480, 352 × 240, 320 × 240) |
| Image Settings | Brightness, saturation, contrast, sharpness are adjustable via web browseror client software |
| Day/Night Switch | Support auto, scheduled |
| Others | Mirror, BLC (areaconfigurable), region of interest (support 1 fixed region) |
| Network | |
| Network Storage | NAS (NFS, SMB/CIFS) |
| Detections | Motion Detection |
| Alarms | Video tampering, network disconnected, IP address conflicted |
| Protocols | TCP/IP, ICMP, HTTP,HTTPS, FTP, DHCP,DNS, DDNS, RTP,RTSP, RTCP, NTP,UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| General | |
| Operating Conditions | -30 °C to 60 °C (-22°F to 140 °F), humidity: 95% or less(non-condensing) |
| Power Supply | 12 VDC ± 25%, PoE (802.3af) |
| Power Consumption | Max. 5 W/6.5W (PoE) |
| Ingress Protection | IP67 |
| IR Range | Up to 30 m |
| Dimensions | 69.1 mm × 66 mm× 172.7 mm ( 2.7" × 2.6" × 6.8") |
| Weight | 500 g (1.1 lb.) |
