Növ	IP
Meqapixel	2 MP
Obyektiv	PTZ
Fokus	2.7 - 13.5
İşıqlandırma	LED
İşıqlandırma məsafəsi	200m
Qoruma	IP67
Material	Metal

Model		DH-SD6CE245U-HNI
Camera
Matrix		1/2.8” STARVIS™ CMOS
Effective pixels		1920 x 1080
RAM/ROM		512 M / 128 M
Scanning system		Progressive
Electronic shutter speed		1/1 s ~ 1/30,000 s
Min. lighting		Color: 0.005Lux F1.6; B/W: 0.0005Lux F1.6; 0Lux F1.6 (IR on)
Signal to noise ratio		More than 55dB
IR distance		Up to 250 m (820ft)
IR control on / off		Auto / Manual
IR LEDs		6
Lens
Focal length		3.95mm ~ 177.7mm
Max. diaphragm		F1.6~F4.95
Viewing angle		70.3° ~ 1.8°
Optical zoom		45x
Focus control		Auto / Manual
Closed focal length		100mm~1000mm
DOOR Distance
Detection	Notification	Recognition	Identification
2345 m (7694ft)	938 m (3077ft)	469 m (1539ft)	234 m (768ft)
PTZ
Pan/Tilt Range		Panning: 0°~360° infinite; Tilt: -20°~90°, auto rotate 180°
Manual control speed		Pan: 0.1°~200°/s; Tilt: 0.1°~120°/s
Preset speed		Pan: 300°/s; Tilt: 200°/s
Presets		300
PTZ mode		5 Templates; 8 Tours; Auto pan; Auto scan
Speed setting		Human-Centric Focal Length/Speed Adaptation
Enable action		Automatically restore to previous PTZ and lens status after power failure
Driving in standby mode		Activate preset/scan/tour/pattern if there is no command within the specified period
Protocol		DH-SD, Pelco-P/D (automatic recognition)
Intelligent properties
Trigger Events		Motion detection, video tampering, scene change, network disconnection, IP address conflict, illegal access, storage anomaly
Automatic tracking		Supports
IVS		Stretch / Invasion / Abandoned / Lost objects
Advanced Smart Features		Face recognition, Heatmap
Video
Compression		H.265+ / H.265 / H.264+ / H.264
Streaming Features		3 streams
Permission		1080P (1920 × 1080) / 720P (1280 × 720) / D1 (704 × 576 / 704 × 480) / CIF (352 × 288 / 352 × 240)
Frame frequency		Main Stream:1080P/1.3M/720P(1~50/60fps)
		Add. stream 1:D1/CIF(1~25/30fps)
		Add. Stream 2: 1080P/1.3M/720P/D1/CIF (1~25/30fps)
Bitrate control		CBR/VBR
Bit rate		H.265/H.264: 448K~8192Kbps
Day Night		Auto (ICR) / Color / B/W
Backlight Compensation		BLC/HLC/WDR (120dB)
White Balance		Auto / ATW / Indoor / Outdoor / Manual
Gain control		Auto / Manual
Noise suppression		Ultra DNR (2D/3D)
Motion Detection		Supports
Area of interest		Supports
Electronic Image Stabilization (EIS)		Supports
Prevent fogging		Supports
Digital zoom		16x
Frame rotation		180°
Privacy mask		Up to 24 zones
Audio
Compression		G.711a / G.711Mu / AAC / G.722 / G.726 / G.729 / MPEG2-L2
Net
Ethernet		RJ-45 (10Base-T/100Base-TX)
Protocol		IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP,ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP,DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1 x
Compatibility		ONVIF Profile S&G, API
Streaming Method		Unicast/Multicast
Max. user access		20 users
Storage		NAS (Network Attached Storage), Local PC for instant recording, Micro SD card 256GB
Web browsing		IE, Chrome, Firefox, Safari
Management software		Smart PSS, DSS, DMSS
Smartphones		IOS, Android
Interface
Video interface		1 port (BNC, 1.0 V [pp], 75 Ohm)
RS485		1
Audio input /out.		eleven
Alarm input /out.		7/2
Protection
Degree of protection		IP67
Anti-vandal protection		IK10
Environment
terms of Use		-40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH
Electrical properties
Power supply		AC24V / 3A(±25%), PoE+(802.3at)
Power consumption		17 W 25 W (IR on, heater on)
General information
Frame		Metal
Color		White
Dimensions		φ209 × 337.4 mm
Net weight		5.8 kg (12.79 lb)
Gross weight		9.1 kg (20.06 lb)

DH-SD6CE245U-HNI

2181.32 azn

Stokda yoxdur

Haqqında

Ətraflı

2181.32 azn
