HAC-HDBW1200R
50.16 azn
Dahua
Analoq
2 MP
20 m
Sabit
2.8
İR
IP67
Plastik
Stokda yoxdur
Haqqında
DAHUA DH-HAC-HDBW1200R-0280B 2MP 2.8MM HDCVI KAMERA
| Növ | Analoq |
| Meqapixel | 2 MP |
| İşıqlandırma məsafəsi | 20 m |
| Obyektiv | Sabit |
| Fokus | 2.8 |
| İşıqlandırma | İR |
| Qoruma | IP67 |
| Material | Plastik |
Ətraflı
| Model | HAC-HDBW1200R-0280B | |
| Camera | ||
| Matrix | 1/2.7" CMOS | |
| Effective pixels | 1920×1080 | |
| Scanning system | Progressive | |
| Electronic shutter speed | PAL:1/25 ~ 1/100000s NTSC:1/30 ~ 1/100000s | |
| Min. lighting | 0.04 Lux / F1.85, 30IRE, 0 Lux IR on. | |
| Signal/Noise Ratio | More than 65dB | |
| IR distance | Up to 20 m (66 ft) | |
| IR Control On / Off | Auto / Manual | |
| IR LEDs | 12 | |
| Lens | ||
| Lens type | Fixed lens/aperture | |
| Focal length | 2.8 mm | |
| Max. diaphragm | F1.85 | |
| Viewing angle | 103° | |
| Focus control | No | |
| Closed focal length | 500 mm 19.69" | |
| DOOR Distance | ||
| DOOR Definition | Distance | |
| Detection | 25 px/m (8 px/ft) | 37 m (121ft) |
| Notification | 63 px/m (19 px/ft) | 15 m (49ft) |
| Recognition | 125 px/m (38 px/ft) | 8 m (26ft) |
| Identification | 250ppm (76 px/ft) | 4 m (14ft) |
| Pan/Tilt/Rotate | ||
| Pan/Tilt/Rotate | Pan:0° ~ 355° Tilt:0° ~ 75° Rotation:0° ~ 355° | |
| Video | ||
| Permission | 1080P (1920×1080) | |
| Frame frequency | 25/30fps 1080P, 25/30/50/60fps 720P | |
| Video output | 1CH HD video output BNC / CVBS video output (can be switched) | |
| Day Night | Auto (IR) / Manual | |
| OSD Menu | Multilingual | |
| BLC Mode | BLC/HLC/DWDR | |
| WDR | DWDR | |
| Gain control | A.G.C. | |
| Noise suppression | 2D | |
| White Balance | Auto / Manual | |
| Smart IR | Auto / Manual | |
| Interface | ||
| Audio interface | No | |
| Protection | ||
| Degree of protection and anti-vandal protection | No | |
| Certificates | ||
| Certificates | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 Subpart B, ANSI C63.4-2014) UL (UL60950-1+CAN / CSA C22.2 No.60950-1) | |
| Environment | ||
| Terms of Use | -40°C ~ +45°C (-40°F ~ +104°F) / Less than 95% RH *Start up at temperatures above -40°C (-40°F). | |
| Storage conditions | -40°C ~ +45°C (-40°F ~ +104°F) / Less than 95% RH | |
| Electrical properties | ||
| Power supply | 12V DC ±30% | |
| Power consumption | Maximum. 3 W (12 VDC, IR on) | |
| General information | ||
| Frame | Plastic | |
| Color | White | |
| Mounting type | Wall | |
| Dimensions | Φ100mm × 74.3mm (Φ3.9" × 2.9") | |
| Net weight | 0.14 kg (0.31 lb) | |
| Gross weight | 0.24 kg (0.53 lb) | |
